Factory Price Vacuum Forming Cutting Machine

FOB Reference Price:Get Latest Price
  • 1 - 999 Sets
    US $5600.00
  • >=1000 Sets
    US $5000.00
Report Suspicious Activity
Overview
Quick Details
Processing Type:
Plastic Thermoforming Machine
Condition:
New
Product Type:
Other
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
HW thermoforming machine
Model Number:
HW-30T
Voltage:
380V/50HZ
Power(W):
2.2kw
Dimension(L*W*H):
260*150*150cm
Weight:
2T
Certification:
CE, UL, CE
Warranty:
One year warranty lifetime maintenance
After-sales Service Provided:
Engineers available to service machinery overseas, Engineers available to service machinery overseas
Name:
Factory price vacuum forming cutting machine
Area of workbench(plastic):
500*1250mm for Blister Hydraulic Cutting Mchine
Area of workbench(pearl cotton):
500*1600 for Blister Hydraulic Cutting Mchine
HS:
8477800000 for Blister Hydraulic Cutting Mchine
Maximum cutting force:
300KN for Blister Hydraulic Cutting Mchine
Application:
Leather, plastic, nylon cloth, paper, cotton and synthetic fiber...
Cooperated Customers:
Egypt, Afghanistan, Canada, Pakistan, UAE, Russia etc.
Color:
Blue and Yellow
Supply Ability
Supply Ability:
10000 Set/Sets per Year
Packaging & Delivery
Packaging Details
Each parts wrapped with stretch film or wooden crates packing(charge).
Container: 1*40HQ
HS Code: 8477800000 for Factory price vacuum forming cutting machine
Port
Shanghai port
Lead Time :
15 days after the order is determined
Product Description

Main Features

1.All the sliding parts of this machine by the hydraulic system for oil lubrication, reducing wear and          prolong the service life of the machine.
   Automatic slow cutting when quick clamp down on knife mold cutting, cutting no size error between      the ground floor.
2.The machine structure changes when the design for the users no worry about possible oil leakage of      the machine.
3.Due to the motor and pump extraposition, good ventilating and cooling conditions, safety operation,        long service life.
4.The setting of the knife mold is rapid, accurate and easy to learn.
   Small motor power, low energy consumption.

Mode
Maximum cutting force
Distance between upper press plate and workbench
Area of workbench
Main motor power
Hydraulic pressureoil mass
HW-30T
300KN
50-160MM
500*1600MM
500*1250MM
2.2KW
150L
HW-35T
350KN
50-160MM
610*1600MM
610*1250MM
2.2KW
180L
HW-50T
500KN
55-180MM
710*1600MM
710*1250MM
3KW
200L
HW-60T
600KN
50-200MM
800*1600MM
900*1250MM
5.5KW
220L
HW-80T
800KN
50-200MM
800*1600MM
800*1250MM
7.5KW
320L
HW-100T
1000KN
50-200MM
900*1600MM
900*1250MM
11KW
330L
Factory show

Why choose us?

1.High working efficiency.
2.Flexible operation.
3.Long service life.
4.Attractive appearance.
5.Our engineers have over 15 years of experience in design and manufacturing.

6.We can provide overseas installation and maintenance services.

Application

The machine is suitable for forming die cutter for leather, plastic, nylon cloth, paper, cotton and synthetic fiber, forming cutting operation of non-metallic materials, particularly applicable to a wide material layer or multilayer cutting blanking.

Our Service
1.High working efficiency.
2.Flexible operation.
3.Long service life.
4.Attractive appearance.
Certifications
Packing & Delivery
FAQ
1. How I can install the machine and How I can operation the machine?

The machine is ease to install, We have the install instruction video, English version manual and it will be shipped together with the machine. Meanwhile we also support the engineer services to your plant. Just tell us what you need from us. We will try our best to fix your problems.

2. What is the machine's guarantee period ?

Guarantee is one year, but maintenance is lifelong. HW mahcine can replace only the elements that are imperfect for material or handwork. Replacement is free and ex-factory. All imperfect elements have to be delivered within 12 months (carriage paid). Guarantee excludes every worn or torn parts. Replacement handwork is excluded and it will be done by the buyer. The supplier is not responsible for any rewards for, damages or last earnings met by buyer. Guarantee is not valid if the machine is used the wrong way or it is not serviced as shown in our technical handbook.

3. How can you guarantee the machine we received in a good condition?

First, we have Q/C department to control the quality from raw material to the finished product. When the machine was finished, we will send you the inspection video or photos. Or you can come to our factory to check it by yourself. As well as we have professional experience for packaging, so you can one hundred precent sure about our quality.

4. Can I get spare parts?

Yes, sure you can. We will enclose some quick wear parts with the machine when you place an order from us.

5.How to order raw material ?

We have many raw material cooperative partners, and we can purchase them for you. Just info us the thickness, number (50kgs/roll). And the raw material will be shipped with machine to you .

6. Is this machine need mould ?

Yes, it is. Moulds need to according to your sample or 3D drawing to making!!

7. How can I get more details about the thermoforming machines? Do you have other models of mahine?

Yes, we have different models of light duty vacuum forming equipment or heavy duty thermoforming equipment. As well as we can customize the machines according to your design, OEM is available. Please write all your doubts in the below small box, we will reply you via Email within 12hours.

8. How can I get your company?

We are located in NO.355 HepengRoad,QingPu District, Shanghai, China. Generally we could provide you the pick-up services once you decide to visit us.

Assurance:

1.Our machine have one year guarantee and lifetime maintenance,and we will be equipped with some        wearing parts free of charge.
2.Our company provide the most favorable price to you based on the principle of high quality and best      service.
3.According to our customer’s requirements, if there is any special requirements or need complete the      machine in advance, we will do our best to meet your demand.

Contact Us

Company Profile:

  Established in July,2010 , Shanghai Yiyou Electromechanical Equipment Co., Ltd is a professional manufacturer and exporter that is concerned with the design, development and production of thermoforming machines We are located in Qingpu Industrial Zone,Qingpu District, Shanghai, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.

  We have over 50 employees, an annual sales figure that exceeds USD 2 million and are currently exporting 50% of our production worldwide. Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction.

  As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching Africa, North America, Domestic Market ,Eastern Europe, South America and Mid East.


  If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
